纯前端实现 PDF 水印添加

<script setup lang="ts">
import * as PDFJS from 'pdfjs-dist'
import { nextTick, ref, watch } from 'vue'

const dialogVisible = ref(false)

const pdfSrc = ref<string>('')
let pdfDoc: any = null
const pdfPages = ref(0)
const pdfScale = ref(1.5)
const currentPage = ref(1)

/* ----------水印相关---------- */
const watermark = ref<string>('Sample Watermark')

function initWatermark() {
  const canvas = document.createElement('canvas')
  canvas.width = 200
  canvas.height = 200

  const ctx = canvas.getContext('2d')
  if (!ctx)
    return canvas

  ctx.rotate((-18 * Math.PI) / 180)
  ctx.font = '14px Vedana'
  ctx.fillStyle = 'rgba(200, 200, 200, 0.3)'
  ctx.textAlign = 'left'
  ctx.textBaseline = 'middle'
  ctx.fillText(watermark.value, 50, 50)

  return canvas
}

function renderWatermark(canvas: HTMLCanvasElement) {
  const ctx = canvas.getContext('2d')
  if (!ctx)
    return

  const watermarkCanvas = initWatermark()
  if (!watermarkCanvas)
    return

  const pattern = ctx.createPattern(watermarkCanvas, 'repeat')
  if (!pattern)
    return

  ctx.rect(0, 0, canvas.width, canvas.height)
  ctx.fillStyle = pattern
  ctx.fill()
}

/* ----------PDF 相关---------- */
// 加载pdf文件
async function loadFile(url: string) {
  PDFJS.GlobalWorkerOptions.workerSrc = `https://cdnjs.cloudflare.com/ajax/libs/pdf.js/${PDFJS.version}/pdf.worker.min.mjs`
  const response = await fetch(url)
  const arrayBuffer = await response.arrayBuffer()

  const loadingTask = PDFJS.getDocument(arrayBuffer)
  loadingTask.promise
    .then(async (pdf: any) => {
      pdf.loadingParams.disableAutoFetch = true
      pdf.loadingParams.disableStream = true
      pdfDoc = pdf // 保存加载的pdf文件流
      pdfPages.value = pdfDoc.numPages // 获取pdf文件的总页数
      currentPage.value = 1 // 初始化为第一页
      await nextTick(() => {
        renderPage(currentPage.value) // 渲染第一页
      })
    })
    .catch((error: any) => {
      console.warn(`pdfReader loadFile error: ${error}`)
    })
}

// 渲染当前页面
function renderPage(num: number): void {
  pdfDoc.getPage(num).then((page: any) => {
    const canvas: any = document.getElementById('pdf-canvas') // 获取页面中的canvas元素
    // 以下canvas的使用过程
    const ctx: any = canvas.getContext('2d')
    const dpr = window.devicePixelRatio || 1
    const bsr
      = ctx.webkitBackingStorePixelRatio
      || ctx.mozBackingStorePixelRatio
      || ctx.msBackingStorePixelRatio
      || ctx.oBackingStorePixelRatio
      || ctx.backingStorePixelRatio
      || 1
    const ratio = dpr / bsr
    const viewport = page.getViewport({ scale: pdfScale.value }) // 设置pdf文件显示比例
    canvas.width = viewport.width * ratio
    canvas.height = viewport.height * ratio
    canvas.style.width = `${viewport.width}px`
    canvas.style.height = `${viewport.height}px`
    ctx.setTransform(ratio, 0, 0, ratio, 0, 0) // 设置当pdf文件处于缩小或放大状态时，可以拖动
    const renderContext = {
      canvasContext: ctx,
      viewport,
    }
    // 将pdf文件的内容渲染到canvas中
    page.render(renderContext).promise.then(() => {
      // PDF渲染完成后，添加水印
      renderWatermark(canvas)
    })
  })
}

// 打开弹窗
function showPdfWindow(src: string) {
  pdfSrc.value = src
}

watch(pdfSrc, () => {
  if (pdfSrc.value) {
    loadFile(pdfSrc.value)
    dialogVisible.value = true
  }
})

// 下一页
function nextPage() {
  if (currentPage.value < pdfPages.value) {
    currentPage.value++
    renderPage(currentPage.value)
  }
}

// 上一页
function prevPage() {
  if (currentPage.value > 1) {
    currentPage.value--
    renderPage(currentPage.value)
  }
}
</script>

<template>
  <div class="container">
    <el-button
      @click="
        showPdfWindow(
          'https://cdn.jsdelivr.net/gh/themusecatcher/[email protected]/Markdown.pdf',
        )
      "
    >
      打开弹窗
    </el-button>

    <el-dialog v-model="dialogVisible" width="80%" title="pdf预览">
      <div class="pdf-container">
        <canvas id="pdf-canvas" />
      </div>
      <div class="pagination-controls">
        <el-button :disabled="currentPage === 1" @click="prevPage">
          上一页
        </el-button>
        <span>{{ currentPage }} / {{ pdfPages }}</span>
        <el-button :disabled="currentPage >= pdfPages" @click="nextPage">
          下一页
        </el-button>
      </div>
    </el-dialog>
  </div>
</template>

<style scoped>
.pdf-container {
  position: relative;
  width: 100%;
  overflow: hidden;
  display: flex;
  justify-content: center;
  align-items: center;
}

.pagination-controls {
  display: flex;
  justify-content: center;
  margin-top: 10px;
}

canvas {
  border: 1px solid #ccc;
  margin: 0 auto;
}
</style>
